Focusrite Scarlett Octopre Dynamic 8 Ch Mic Preamp and Analog Compressor

SKU: MIDSCOCTOPREDYN Category: Tag:

Description

8 Channel mic preamp input dengan koneksi ADAT, memliki fitur utama analog input direct ke analog output dan 8 channel koneksi digital lewat ADAT serta built in compressor

Dengan perangkat ini dapat menambah jumlah channel dan preamp dari audio interface/soundcard dengan digital output/input ADAT yang anda miliki.



Spesifikasi

SUPPORTED SAMPLE RATES

44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz

MICROPHONE INPUTS

Frequency Response
20Hz – 20kHz +0.5/-1.5dB
Dynamic Range
109 dB (A-Weighted)
THD+N
<0.001%
Noise EIN
-127 dBu
Maximum input level (without pad)
+8 dBu
Maximum input level (with pad)
+16 dBu
Gain Range
50 dB
Input Impedance
3 kΩ

LINE INPUTS

Frequency Response
20Hz – 20kHz +0.5/-1.5dB
Dynamic Range
109 dB (A-Weighted)
THD+N
<0.002%
Maximum input level
+22 dBu
Gain Range
50 dB
Input Impedance
49 kΩ

INSTRUMENT INPUTS

Frequency Response
20Hz – 20kHz +0.5/-1.5dB
Dynamic Range
108 dB (A-Weighted)
THD+N
<0.01%
Maximum input level
+13 dBu
Gain Range
50 dB3
Input Impedance
1 MΩ

LINE OUTPUTS

Maximum Output Level (0 dBFS)
+16dBu @ 0dBFS, or >21dBu where ADAT output is not used
THD+N
<0.001%
Ouput Impedance
136 Ω (Balanced) – for units with serial number ≤ W960065003383
576 Ω (Balanced) – for units with serial number > W960065003383

Dimensi & Berat

Berat 8000 Gram
Dimensi 50 x 45 x 30

Garansi Resmi DIstributor 1 Tahun
