Genelec 8030 8030C Active Two-Way 5″ Studio Monitor Dark Grey Producer
Rp10.456.000
4 in stock
Description
Genelec 8030C Active Two-Way 5″ Studio Monitor (Single) Dark Grey Producer Finish
Spesifikasi
Inputs
1 x XLR balanced
Frequency Response
54 Hz – 20 kHz ( 2.0 dB)
Cut-Off Frequency
Lower Cut-Off Frequency, -6 dB: < 47 Hz
Upper Cut-Off Frequency, -6 dB: > 25 kHz
Crossover Frequency
3.0 kHz
LF Amplifier 50W
HF Amplifier 50W
Maximum SPL
Short Term: 104 dB @ 3.3′ / 1 m
Long Term (RMS): 96 dB @ 3.3′ / 1 m
Peak Output (Pair): 110 dB
Noise Level
Noise Level: 5 dBA (self-generated in free field at 3.3′ / 1 m on axis)
THD
Harmonic Distortion (at 85 dB SPL @ 3.3′ / 1 m on axis):
50 to 100 Hz: < 2 %
100 Hz or Higher: < 0.5 %
Low Frequency Driver 5.0" / 127.0 mm
High Frequency Driver 0.8" / 19.1 mm metal dome
Level Control
Dial: -6 to +6 dB
Tone Controls
Treble Tilt Control Operating Range: 0 to 2 dB @ 15 kHz
Bass Roll-Off Control: 4 dB step @ 55 Hz
Bass Tilt Control Operating Range in 2 dB Steps: 0 to 6 dB @ 100 Hz
Desktop Control: 4 dB @ 160 Hz
Mounting Options
Tabletop (with included Iso-Pod)
3/8" thread on base
Two 0.24 x 0.39" (6 x 10 mm) threaded holes for Omnimount size 20.5 brackets or the included keyhole wall-mount adapter
Enclosure Material
Die-cast aluminum
Power Supply (AC)
100 - 240 VAC, 50/60 Hz
Distortion
Amplifier System Distortion at Nominal Output: THD < 0.05 %
Voltage Range 10%
Power Consumption
Idle: 3 W
Standby: < 0.5 W
Full Output: 60 W
Dimensions (H x W x D)
With Iso-Pod: 11.8 x 7.4 x 7.0" / 299.0 x 189.0 x 178.0 mm
Without Iso-Pod: 11.2 x 7.4 x 7.0" / 285.0 x 189.0 x 178.0 mm
Weight
11.0 lb / 5.0 kg
Additional information
Weight | 5000 g |
---|
