Stereo Direct Box Passive Mackie MDB-2P



Mackie MDB-2P


Route a Stereo Instrument to Mic Inputs

Converts Unbalanced to Balanced

Converts High Impedance to Low Impedance

Two 1/4″ Unbalanced Inputs

Two 1/4″ TS Thru Jacks

Two XLR 3-Pin Balanced Outputs

-15 dB Pads Prevent Overloading

Ground-Lift Switch Minimizes Hum

No Power Source Required

Heavy-Gauge Steel Construction


TheMackie MDB-2Pis a stereo passive direct box designed to connect two mono instruments or a single stereo instrument to microphone preamps for musicians and audio engineers in recording sessions, houses of worship, and live stage applications. It converts high-impedance, instrument-level signal via its 1/4″ TS unbalanced inputs to low-impedance, mic-level outputs via balanced XLR 3-pin jacks. Two 1/4″ TS thru jacks allow simultaneous connection to amplifiers or pedalboards.

Each channel offers a -15 dB pad for reducing the input level to prevent distortion when using a high-gain source. The ground-lift switch inhibits hum caused by ground loops. Due to passive design principles, the MDB-2P requires no batteries or power supply. Its sturdy steel chassis enables confident use in the studio or on the road.

Connect two mono instruments such as guitars or basses or a stereo instrument such as a keyboard to microphone preamps

Converts high-impedance, unbalanced 1/4″ TS inputs to low-impedance, balanced XLR mic-level outputs

1/4″ thru jacks for routing to amplifiers or pedalboards

Per-channel -15 dB pad prevents overloading when accepting signal from a loud source

Ground-lift switch minimizes hum

Passive design requires no batteries or power supply

Additional information

Weight 1100 kg
